Estimated Lead Time : 4 – 8 weeks.
Manufacturer : Rosemount
Product No. : 3051SMV5M22G4N2A11A1AD4I5L2M5Q4T1+0305RC52B11B4L4
Product Type : 3051SMV Scalable MultiVariable Transmitter + 305 Integral Manifold
3051SMV5M22G4N2A11A1AD4I5L2M5Q4T1 = Scalable MultiVariable Transmitter
Performance class : 5 = Classic MV: 0.04% span DP accuracy, 100:1 rangedown, 15-year stability
Multivariable type : M = Measurement with fully compensated mass and energy(3) flow calculations
Measurement type : 2 = Differential pressure and static pressure
Differential Pressure Range : 2 = 250 to 250 inH2O (–621,60 to 621,60 mbar)
Static pressure type : G = Gage
Static pressure range : 4 = Range 4, –14.2 to 3626 psig (–0,98 to 250,00 bar)
Temperature input : N = None
Isolating diaphragm : 2 = 316L SST
Process connection : A11 =Assemble to Rosemount 305/306 integral manifold
Transmitter output : A = 4–20 mA with digital signal based on HART protocol
Housing style : 1A = Plantweb housing, Aluminum, ½–14 NPT
Ground screw : D4 = External ground screw assembly
Product certifications : I5 = FM Intrinsically Safe; Nonincendive
O-rings : L2 = Graphite-filled PTFE O-ring
Digital display : M5 = Plantweb LCD display
Calibration certification : Q4 = Calibration certificate
Transient protection : T1 = Transient terminal block
Weight : 8 Kg
0305RC52B11B4L4 = 305 Integral Manifold
Manufacturer : R = Rosemount
Manifold style : C = Coplanar
Manifold type : 5 = Five valve
2
Body : 316/316L SST
Bonnet : 316 SST
Stem and tip/ball : 316 SST
Process connection : B = 1
Packing material : 1 = PTFE
Valve seat : 1 = Integral
Mounting brackets : B4 = SST mounting bracket for 2-in. pipe mounting, 300 SST bolts
Bolt materials : L4 = Austenitic 316 SST bolts
Weight : 3 Kg
Total Shipping Weight : 11 Kg
