Estimated Lead Time : 2 – 3 Weeks
Manufacturer: Rosemount Inc.
Part number:3051TG1A2B21BS1/1199WNA95SSCW30LA002
Model: 3051T,In-line pressure transmitter
Pressure type: G, Gage
Pressure range: 1,–14.7 to 30 psi (–1,01 to 2,06 bar)
Transmitter output:A, 4–20 mA with Digital Signal Based on HART Protocol
Process connection style:2B, 1/2–14 NPT female (range 1–5 only)
Isolating diaphragm: 2,316L SST
Process connection wetted parts material:2, 316L SST
Sensor fill fluid: 1,Silicone
Housing material:B, Aluminium, conduity entry size, 1/2–14 NPT
Diaphragm seal assemblies: S1, Assemble to one Rosemount 1199 seal
Model: 1199, Seal system
Connection type: W, all welded, one seal system
Seal fill fluid: N, Neobee M-20,specific gravity,0.94
Temperature limit: no extension, 5 to 401 °F
(–15 to 205 °C), 2in,(50mm) extension,5 to 437 °F
(–15 to 225 °C), 4in,(100mm) extension,5 to 437 °F(–15 to 225 °C), thermal optimizer,5 to 437 °F
(–15 to 225 °C)
Seal connection type: A, direct mounted
Direct mount connection type: 95, In-line one-seal system,
Extension length:direct mount, no extension
Connection type: All welded
Weight: 1.4 kg
Shipping weight: 2.0kg
