Manufacturer : Bently Nevada
Part Number : 3500/42M
Channel Type : Radial Vibration, Axial Position, Eccentricity, Differential Expansion, Accceleration, Velocity, Acceleration2, Velocity2, Circular Acceptance Region, Shaft Absolute.
Number of Channels : Four (2,3)
Power Consumption : 7.7 watts, typical
Signal : Accepts from 1 to 4 proximity, velocity or acceleration transducer signals
Standard I/O : 10 k? (Proximitor and acceleration inputs)
Radial Vibration : 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil)
Eccentricity 3.94 mV/µm (100 mV/mil) or 7.87 mV/µm (200 mV/mil)
Power Supply : -24 Vdc
Voltage Compliance (currentoutput) : 0 to +12 Vdc range across load. Load resistance is 0 to 600 ?.
Shaft Absolute Output Impedance : 300 ?
Signal Conditioning : Specified at +25 ºC (+77 ºF) unless otherwise noted.
Eccentricity Accuracy : Within ±0.33% of full-scale typical ±1% maximum
Acceleration Accuracy : Within ±0.33% of full-scale typical ±1% maximum. Exclusive of filters
Accuracy of alarm setpoints : Within 0.13% of the desired value
System Weight (typical) : Monitor Module; 0.91 kg (2.0 lb)
I/O Modules (non-barrier); 0.20 kg (0.44 lb)
I/O Modules (barrier); 0.46 kg (1.01 lb)
Shipping Weight : 3 kg
