BMH0703P01A2A Schneider Electric servo motor BMH, Lexium 32, 3.4Nm, 8000rpm, untapped shaft, without brake, IP54, 128bit encoder, 3 phases

Estimated Lead Time : 1 – 10 working days.

Manufacturer : Schneider Electric

servo motor BMH, Lexium 32, 3.4Nm, 8000rpm, untapped shaft, without brake, IP54, 128bit encoder, 3 phases

Main

Product or component type : Servo motor

device short name : BMH

Maximum mechanical speed : 8000 rpm

Continuous stall torque

3.4 N.m for LXM32.D18N4 at 6 A, 400 V, three phase

3.4 N.m for LXM32.D18N4 at 6 A, 480 V, three phase

Peak stall torque

10.2 N.m for LXM32.D18N4 at 6 A, 400 V, three phase

10.2 N.m for LXM32.D18N4 at 6 A, 480 V, three phase

Nominal output power

1300 W for LXM32.D18N4 at 6 A, 400 V, three phase

1300 W for LXM32.D18N4 at 6 A, 480 V, three phase

Nominal torque

2.4 N.m for LXM32.D18N4 at 6 A, 400 V, three phase

2.4 N.m for LXM32.D18N4 at 6 A, 480 V, three phase

Nominal speed

5000 rpm for LXM32.D18N4 at 6 A, 400 V, three phase

5000 rpm for LXM32.D18N4 at 6 A, 480 V, three phase

Product compatibility : LXM32.D18N4 at 400…480 V three phase

Shaft end : Smooth shaft

IP degree of protection : IP54 standard

Speed feedback resolution : 131072 points/turn

Holding brake : Without

Mounting support : International standard flange

Electrical connection : Rotatable right-angled connectors

Complementary

Range compatibility : Lexium 32

[Us] rated supply voltage : 480 V

Network number of phases : Three phase

Continuous stall current : 3.91 A

Continuous power : 1.68 W

Maximum current Irms : 12.6 A for LXM32.D18N4

Maximum permanent current : 12.57 A

Second shaft : Without second shaft end

Shaft diameter : 14 mm

Shaft length : 30 mm

Feedback type : Single turn SinCos Hiperface

Motor flange size : 70 mm

Number of motor stacks : 3

Torque constant : 0.87 N.m/A at 120 °C

Back emf constant : 55.8 V/krpm at 120 °C

Number of motor poles : 10

Rotor inertia : 1.67 kg.cm²

Stator resistance : 2.65 Ohm at 20 °C

Stator inductance : 8.6 mH at 20 °C

Stator electrical time constant : 3.2 ms at 20 °C

Maximum radial force Fr

730 N at 1000 rpm

580 N at 2000 rpm

510 N at 3000 rpm

460 N at 4000 rpm

430 N at 5000 rpm

400 N at 6000 rpm

Maximum axial force Fa : 0.2 x Fr

Type of cooling : Natural convection

Length : 186 mm

Centring collar diameter : 60 mm

Centring collar depth : 2.5 mm

Number of mounting holes : 4

Mounting holes diameter : 5.5 mm

Circle diameter of the mounting holes : 82 mm

Product weight : 3 kg

Shipping Weight : 4 Kg
