EL3204 Beckhoff EtherCAT Terminal, 4-channel analog input, temperature, RTD (Pt100), 16 bit

Estimated Lead Time: 4-6 Weeks

Part Number : EL3204

Manufacturer : BECKHOFF

EL3204 | Beckhoff | EtherCAT Terminal, 4-channel analog input, temperature, RTD (Pt100), 16 bit

Shipping Weight : 2 Kg

EL3204 | EtherCAT Terminal, 4-channel analog input, temperature, RTD (Pt100), 16 bit

Technical data : EL3204, ES3204

Number of inputs : 4

Power supply : via the E-bus

Technology : 2-wire

Distributed clocks : –

Input filter limit frequency : typ. 1 kHz

Sensor types : Pt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni1000, resistance measurement (e.g. potentiometer, 10 Ω…1/4 kΩ), KTY sensors (types see documentation)

Connection method : 2-wire

Resolution : 0.1 °C per digit

Conversion time : approx. 85 ms default setting, 2…800 ms configurable

Temperature range : -200…+850 °C (Pt sensors); -60…+250 °C (Ni sensors)

Measuring current : < 0.5 mA (load-dependent) Measuring error : < ±0.5 °C for Pt sensors Electrical isolation : 500 V (E-bus/signal voltage) Current consumption power contacts : – Current consumption E-bus : typ. 190 mA Bit width in the process image : 4 x 32 bit RTD input Special features : integrated digital filter, limit value monitoring Weight : approx. 60 g Operating/storage temperature : -25…+60 °C/-40…+85 °C Relative humidity : 95 %, no condensation EMC immunity/emission : conforms to EN 61000-6-2/EN 61000-6-4 Vibration/shock resistance : conforms to EN 60068-2-6/EN 60068-2-27 Protect. class/installation pos. : IP20/variable Pluggable wiring : for all ESxxxx terminals Approvals/markings : CE, UL, ATEX, IECEx, cFMus Ex marking : ATEX: II 3 G Ex nA IIC T4 Gc cFMus: Class I, Division 2, Groups A, B, C, D Class I, Zone 2, AEx ec IIC T4 Gc Housing data : EL-12-8pin Design form : compact terminal housing with signal LEDs Material : polycarbonate Dimensions (W x H x D) : 12 mm x 100 mm x 68 mm Installation : on 35 mm DIN rail, conforming to EN 60715 with lock Side by side mounting by means of : double slot and key connection Marking : labeling of the BZxxx series Wiring : solid conductor (e), flexible conductor (f) and ferrule (a): spring actuation by screwdriver Connection cross-section : s*: 0.08…2.5 mm², st*: 0.08…2.5 mm², f*: 0.14…1.5 mm² Connection cross-section AWG : s*: AWG 28…14, st*: AWG 28…14, f*: AWG 26…16 Stripping length : 8…9 mm Current load power contacts : Imax: 10 A Special terminals : EL3204 : EtherCAT Terminal, 4-channel analog input, temperature, RTD (Pt100), 16 bit ES3204 : EtherCAT Terminal, 4-channel analog input, temperature, RTD (Pt100), 16 bit, pluggable wiring Shipping Weight : 2 Kg
