Estimated Lead Time : 4-6 Weeks
Manufacturer : BECKHOFF
Part Number : KS3468
Number of inputs : 8
Power supply : via the K-bus
Signal voltage : 0…10 V
Technology : single-ended
Internal resistance : > 130 kΩ
Common-mode voltage UCM : –
Conversion time : ~ 4 ms
Resolution : 12 bit
Measuring error : < ±0.3 % (relative to full scale value) Electrical isolation : 500 V (K-bus/signal voltage) Current consumption power contacts : - Current consumption K-bus : typ. 140 mA Bit width in the process image : input: 8 x 16 bit data (8 x 8 bit control/status optional) Configuration : no address or configuration setting Special features : high packing density Operating/storage temperature : 0…+55 °C/-25…+85 °C Relative humidity : 95 %, no condensation Vibration/shock resistance : conforms to EN 60068-2-6/EN 60068-2-27 EMC immunity/emission : conforms to EN 61000-6-2/EN 61000-6-4 Protect. rating/installation pos. : IP20/variable Pluggable wiring : for all KSxxxx Bus Terminals Approvals/markings : CE, UL, ATEX, DNV GL Ex marking : II 3 G Ex nA IIC T4 Gc Design form : terminal housing with pluggable wiring level Material : polycarbonate Installation : on 35 mm DIN rail, conforming to EN 60715 with lock Side by side mounting by means of : double slot and key connection Marking : labeling of the BZxxx series Wiring : spring actuation by screwdriver Connection cross-section : s*: 0.08…1.5 mm², st*: 0.08…1.5 mm², f*: 0.14…1.5 mm² Connection cross-section AWG : s*:AWG 28…16, st*: AWG 28…16, f*: AWG 26…16 Stripping length : 9…10 mm Current load power contacts : Imax: 10 A Dimensions (L x W X H) : 6.8 cm x 1.2 cm x 10.0 cm Weight : 0.075 kg Shipping Weight : 2 Kg
