Power Quality analysis:Up to the 31st harmonic
Type of measurement:
Energy
Active and reactive power
Current
Voltage
Frequency
Power factor
Network frequency: 50/60 Hz
In rated current: 1A/5A
Power consumption in VA: <= 10 VA at 415 V Display Type: Backlit LCD Sampling rate: 64 samples/cycle Measurement current: 10...9000mA Frequency measurement range: 45...65 Hz Number of inputs: 2 digital Number of outputs: 2 digital / 2 relay Information displayed: Tariff 4 Accuracy class: Class 0.5S (active energy according to IEC 62053-22) Communication port support: RS485 Data Recording: Min/max of instantaneous values Time stamping Data Logs Event logs Alarm logs Maintenance logs Memory capacity: 256 kB Mounting mode: Flush-mounted Shipping Weight: 1.43 kg
