Manufacturer : Schneider Electric
Product No. : STBNCO2212
Product Type : Network Interface Module, Modicon STB
Range of product : Modicon STB distributed I/O solution
Product or component : type Standard Network Interface Module
Integrated connection :
type CANopen bus conforming to CIA DS-301 9-way male SUB-D connector double shielded twisted pair (bus)
CANopen bus conforming to CIA DS-301 HE-13 (RS232 port)
CANopen bus conforming to CIA DS-301 8-way female (RS232 port)
Number of segments : 1 primary, maximum 6 extensions
Number of slave : 127
Transmission rate :
1 Mbit/s for bus length of 30 m
10 kbit/s for bus length of 5000 m
Structure type : CAN field bus
Number of addressable I/O module : 0…32 per island
Communication service :
Service Data Object (SDO)
Network management (NMT)
Process Data Object (PDO)
[Us] rated supply voltage : 24 V DC
Power supply type : SELV
Maximum supply current : 700 A
Supply voltage limits : 19.2…30 V
Input current : 430 mA for supply circuit
Nominal output current :
0.575 A at 60…70 °C
1.2 A
Output voltage : 5.25 V DC (tolerance: +/- 0.21 %) for logic bus
Marking : CE
Overvoltage category : II
Status LED :
1 LED (green) CAN RUN
1 LED (green) island state (RUN)
1 LED (green) power supply (PWR)
1 LED (red) CAN ERR
1 LED (red) module error (ERR)
1 LED (yellow) test mode
Shipping Weight : 2 Kg
