Estimated Lead Time : 6 – 8 weeks
Manufacturer : SICK Sensors
Part Number : C40E-S138
Application : Explosive areas
Ex-approvals : ATEX for gas: II 3G Ex nA op is IIC T4 Gc X / ATEX for dust: II 3D Ex tc IIIC T135°C Dc
System part : Receiver
Resolution : 30 mm
Scanning range : 21 m
Protective field height : 1,500 mm
Response time : 14 ms (Uncoded) / 24 ms (code 1 or code 2)
Synchronization : Optical synchronisation
Protection class : III (IEC 61140)
Supply voltage VS : 24 V DC (19.2 V … 28.8 V) 1)
Residual ripple : ≤ 10 % 2)
Output signal switching devices (OSSDs) :
Type of output : 2 PNP semiconductors, short-circuit protected, cross-circuit monitored 3)
ON state, switching voltage HIGH : 24 V DC (VS – 2.25 V DC … VS)
OFF state, switching voltage LOW : ≤ 2 V DC
Current-carrying capacity per OSSD : ≤ 500 mA
Application diagnostic output (ADO) :
Type of output : PNP semiconductor, short-circuit protected 3)
Output voltage HIGH (active) : 24 V DC (VS – 4.2 V DC … VS)
Output voltage LOW (deactivated) : High resistance
Output current HIGH (active) : ≤ 100 mA
Dimensions : See dimensional drawing
Housing cross-section : 48 mm x 40 mm
Housing material : Aluminum extruded profile
Shipping weight : 4 kg
