Estimated Lead Time : 6 – 8 weeks.
Manufacturer : SICK Sensors
Part Number : WL12-3N2461
Functional principle : Photoelectric retro-reflective sensor
Functional principle detail : Autocollimation
Sensing range max. : 0 m … 2 m 1)
Sensing range : 0 m … 1.3 m 1)
Emitted beam
Light source : LED 2)
Type of light : Visible red light
Light spot size (distance) : Ø 2 mm (90 mm)
Key LED figures
Wave length : 640 nm
Adjustment : Potentiometer, 5 turns
Angle of dispersion : Approx. 5°
Special features : Without polarisation filter
Special applications : Detecting small objects
Items supplied : 2 x clamps BEF-KH-W12, incl. screws
Supply voltage UB : 10 V DC … 30 V DC 1)
Ripple : < 5 Vpp 2) Current consumption : 40 mA 3) Protection class : III Digital output Type : NPN Switching mode : Light/dark switching Signal voltage NPN HIGH/LOW : Approx. VS / < 2.5 V Output current Imax. : ≤ 100 mA Response time : ≤ 330 µs 4) Switching frequency : 1,500 Hz 5) Output function : Complementary Circuit protection : A 6) C 7) D 8) Special feature : Focused optics Housing : Rectangular Dimensions (W x H x D) : 15.6 mm x 48.5 mm x 42 mm Connection : Male connector M12, 4-pin Material Housing : Metal Front screen : Plastic, PMMA Weight : 120 g Shipping weight : 1.1 kg
