Range of product : OsiSense XS
Series name : Application
Sensor type : Inductive proximity sensor
Device application : Rotation monitoring
Sensor name : XSA
Sensor design : Cylindrical M30
Size : 81 mm
Body type : Fixed
Detector flush mounting acceptance : Flush mountable
Type of output signal : Discrete
[Sn] nominal sensing distance : 0.39 in (10 mm)
Discrete output function : 1 NC
Electrical connection : Cable
[Us] rated supply voltage : 12…24 V DC
IP degree of protection : IP67 conforming to IEC 60529
Thread type : M30 x 1.5
Detection face : Frontal
Operating zone : 0…0.31 in (0…8 mm)
Differential travel : 3…15% of Fr
Repeat accuracy : 3% of Sr
Wire insulation material : PvR
Status LED : 1 LED red output state
Run-up delay at power-up : 0 s without
Marking : CE
Threaded length : 2.24 in (57 mm)
Height : 1.18 in (30 mm)
Length : 3.19 in (81 mm)
Product weight : 0.66 lb(US) (0.3 kg)
Product certifications : CCC,CSA ,UL
Ambient air temperature for operation : -13…158 °F (-25…70 °C)
Category : 22486 – SENSORS, proxIMITY
Discount Schedule : DS2
GTIN : 00785901628231
Nbr. of units in pkg. : 1
Package weight(Lbs) : 0.14000000000000001
Returnability : N
Country of origin : FR
Shipping weight : 1kg
