Estimated Lead Time: 6 – 8 Weeks.
Manufacturer : SICK Sensors
Part Number : C40E-0304DB010
Sub product family : deTec4 HG
Application : Normal industrial environment
System part : Receiver
Resolution : 40 mm
Scanning range : 21 m
Protective field height : 300 mm
Response time : 9 ms
Synchronization : Optical synchronisation
System connection : Hirschmann male connector M26, 12-pin
Direction of cable connection : Straight
Conductor cross section : 0.75 mm²
Permitted cable length : 50 m
Extension connection : Hirschmann female connector M26, 12 pin
Configuration method : Female connector M8, 4-pin
Display elements : 7-segment display
Dimensions : See dimensional drawing
Housing cross-section : 48 mm x 40 mm
Housing material : Aluminum extruded profile
Shipping Weight : 2 kg
