Analog positioning sensors MPS-160TSNP0

Estimated Lead Time: 4-6 weeks

Manufacturer: SICK Sensors

MPS-160TSNP0

Analog positioning sensors

MPS

Type:MPS-160TSNP0

Part number: 1053839

Cylinder type :T-slot

Cylinder types with adapter :

Round body cylinder

Dovetail groove cylinder

SMC rail CDQ2

SMC rail ECDQ2

Measuring range :160 mm

Housing length :173 mm

Output function :Analog

Electrical wiring :DC 4-wire

Analog output (voltage) :0 V … 10 V

Analog output (current) :4 mA … 20 mA

Enclosure rating :IP 67

Supply voltage :15 V DC … 30 V DC

Max. load resistance :500

Min. load resistance :2 k

Protection class :III

Required magnetic field sensitivity, typ. :3 mT

Resolution, typ. :0.03% FSR (max. >= 0.05 mm) 3)

Linearity error, typ. :0.3 mm

Repeat accuracy, typ. :0.06% FSR (>= 0.1 mm) 3)

Sampling rate, typ. :1 ms

Status indicator LED :Yes

Reverse polarity protection :Yes

Short-circuit protection :Yes

Ambient operating temperature :–20 °C … +70 °C

Shock and vibration resistance :30 g, 11 ms / 10 … 55 Hz, 1 mm

EMC :According to EN 60947-5-2 4)

Housing material :Plastic

Connection type :Cable with M8 male connector, 4-pin, 0.3 m 5)

Cable material :PUR

Conductor cross-section :0.8 mm²

UL File No. :NRKH.E181493

Shipping Weight: 1 Kg

Download PDF File MPS-160TSNP0
